QL系列



星标QL系列强力粉碎机是一种粉碎功能强大的多用途机器,主要用作粉碎各种软硬塑胶,将块状、条状及水口塑胶粉碎成颗粒,对塑胶次品、废品、水口料的迅速回起到重要作用,提高塑胶的利用率。其既可做在线机边粉碎机,置于主机边;也可做某生产区域线下集中处理粉碎机。



QL series power crusher is a kind of multi-purpose machine with powerful crushing function, mainly used for crushing all kinds of soft and hard plastics, crushing the block, strip and water-mouth plastic into particles, playing an important role in the rapid return of plastic defects, waste products and water-mouth material, and improving the utilization rate of plastics. It can be used as on-line machine edge crusher, placed on the side of the main machine; Can also do a production area line centralized processing crusher.



机器特点:

1.高铬工具钢,间隙可调,经久耐用

2.超大惯性轮,钮矩大,产能高.

3.重荷型轴承及防尘装置,并有防音隔板,能有效防止震动和噪音

4.安全装置连锁设计,保护机器和人员安全.

5.交替式切削有效减少粉尘及节能

6.电机过载保护,过力调脱.

7.移动脚轮,方便摆放.

8.拆装式设计,易于维护保养.

Machine features:

1. High chromium tool steel, adjustable gap, durable

2. Super large inertia wheel, big button moment, high productivity.

3. Heavy load bearing and dustproof device, and soundproof partition, can effectively prevent vibration and noise

4. Interlocking design of safety devices to protect the safety of machines and personnel.

5. Alternate cutting can effectively reduce dust and save energy

6. Motor overload protection, overforce adjustment.

7. Move casters for easy placement.

8. Disassembly design, easy maintenance.































粉碎机参数:



型号

QL-300

QL-400

QL-500

QL-600

QL-700

QL-800

电机功率(kw

5.5

7.5

11

15

18.5

30

主轴转速(r/min

610

580

600

500

490

440

主轴直径(mm

72

72

78

82

110

110

动刀数(把)

9

12

15

18

21

24

定刀数(把)

2

2

2

4

4

4

旋转直径(mm

215

245

245

290

360

400

进料口尺寸(mm

300*200

400*250

500*285

600*315

685*315

800*450

粉碎能力

150-200

250-400

300-500

500-600

600-700

700-800

筛网直径(Φ)

8

10

10

12

12

12

机器净重(kg

310

430

590

862

1326

1846

外形尺寸A*B*Cmm

1220*720*1200

1340*870*1450

1450*1000*1540

1730*1160*1870

1960*1270*2180

2220*1380*2380
